PANAMAX MAX® ImagePro™ EX 15 Amp Surge Protector Firewall Copier power bar Automatic Voltage Monitoring

Panamax


Firewall for Noise™ Circuitry This technology provides enhanced Neutral-to-Ground Noise Filtration for your digital office equipment. EMI/RFI noise can contaminate the equipment safety ground, which in turn will contaminate the connected digital equipment, and prevent it from operating at peak performance levels. GFCI Compatibility This circuit features an improved 2-stage common-mode architecture that provides compatibility for GFCI’s and NEC article 250.6. Complies with UL 1283 : Electromagnetic Interference Filters. Automatic Voltage Monitoring (AVM) This power monitoring system acts as a gate to prevent unsafe voltages from damaging sensitive electronic equipment. It automatically detects a prolonged over-voltage and disconnects the power to the connected equipment, then reconnects it when the power returns to a safe level. It even protects the MAX® ImagePro™ unit. Wiring Fault Safety Shutoff This technology will detect a miswired wall receptacle or an open-ground by monitoring the voltage between neutral and ground. If an unsafe condition exists, the MAX® ImagePro™ will disconnect the power from the connected equipment. Complies with UL 991: Tests for safety-related controls employing solid-state devices.



Technical Specifications for the MAX® ImagePro™ EX 15 Amp



AC SPECIFICATIONS
Protect or Disconnect Circuitry Yes
Thermal Fusing Yes
Catastrophic Surge Circuit Yes
Single Pulse Energy Dissipation 2010 Joules
Spike Capacity 60,000A
EMI/RFI Noise Filtration N-G: 70 dB (200KHz-1 MHz); L-N 85 dB (400KHz-1MH
Line Voltage 120VAC, 50/60 Hz
Clamping Level (TVSS Voltage) 330V
Initial Clamping Level 200V Peak/141V RMS
Overvoltage Shutoff 138V+/-8V
Undervoltage Shutoff 86V+/-6V
Protection Modes L-N, L-G, N-G
Maximum Current Rating 15A (1800W)
Response Time <1ns



PRODUCT FEATURES
Number of Outlets 3
Always On Outlets 3
Switched Outlets
Delayed Outlets
Cord Length 8 ft.
Connections Straight
Length 10.25"
Width 4.75"
Height 2.5"
Weight 4.5 lbs.



TELCO SPECIFICATIONS
SignalPerfect Circuitry Yes
Fuseless / Auto Resettable
Clamping Level TEL 260 V/LAN 7V
Capacitance 30pf (approx.)
Suppression Modes Metallic & Longitudinal
Wires Protected 2 wire / I pair (Pins 4,5)
Connectors RJ-45



AGENCY & WARRANTY
Agency Approval cULus
Product Warranty Length Lifetime
Connected Equipment Policy Length Lifetime
Connected Equipment Policy Amount $5,000,000
Lightning Protection Yes



COAX SPECIFICATIONS
Not Applicable



PACKAGING SPECIFICATIONS
Packaging Type Retail Box
Packaging Length 13.25"
Packaging Width 8.75"
Packaging Height 3.125"
Master Carton Length 13.25"
Master Carton Width 9"
Master Carton Height 13"
Master Carton Weight 19 lbs.
Master Carton Quantity 4



SCL/8 SPECIFICATIONS
Not Applicable



RCA SPECIFICATIONS
Not Applicable
